3''-95mm DTH Drill Bit for Water Well Drilling and Mining with Heat Treatment and Flat Face Design

Name: 395mm DTH Drill Bit for Water Well Drilling and Mining with Heat Treatment and Flat Face Design
Brand: SOLLROC
Price: 50 USD

China 3''-95mm DTH Drill Bit for Water Well Drilling and Mining with Heat Treatment and Flat Face Design wholesale

Place of Origin : Hunan, China

Brand Name : SOLLROC

MOQ : 1

Price : $50

Diameter : 90-105mm

Weight : 4.4 KG

Material : carburized steel

Processing Type : heat treatment and machining process

Bit diameter : 95mm

Flushing holes : 2 * 14

Gauge Buttons : 6*14

Front Buttons : 4*13

Button Dia : 14mm, 13mm

Face design : flat face or concave

Air Compressor : High air pressure

Machine Type : Drilling Tool

Type : DRILL BIT

Weight (Kg) : 4.7

Inverted pilot : Yes

Contact Now

Product Description

If for instance your application involves drilling though a variety of rock types, with fractures or fissures, then a flat face design would likely give the best results. The flat face copes will with any ledges and tends not to get stuck or pinched in the formation.The other main type of face design is the concave. The concave design is suitable if the hole is particularly deep or if directional control is important. The drill string can often deviate from vertical, taking the path of geological least resistance. The inverted pilot design found on the concave face means that the drilling system can maintain vertical alignment and improve directional control of the borehole.

Technical parameters

Bit diameter

Flushing holes

No.*Button Dia.mm

Weight

(Kg)

inch

Gauge Buttons

Front Buttons

3 3/4''

2 * 14

6*14

4*13

4.7

Images

Shipping & Package

Shipping

By Air, By Sea or By express.

Package

Ply - wooden cases + Pallet

3''-95mm DTH Drill Bit for Water Well Drilling and Mining with Heat Treatment and Flat Face Design Images
